FLOWSIC600-XT ultrasonic flowmeter | Endress Hauser E+H

Custody transfer natural gas measurement with intellCustody transfer natural gas measurement with intelligent diagnostic functionsigent diagnostic functions

Automation Components

Specs at a glance

Measured variables Volumetric flow a. c., volume a. c., gas velocity, Speed of sound, optional volume correction via integrated, electronic volume corrector (EVC)

Measuring Medium Natural gas (with up to 30% hydrogen), air, natural gases containing increased levels of CO2, N2, H2S, O2, H2

Nominal pipe size 3 ″ … 56 ″ (DN 80 … DN 1400), other nominal pipe sizes on request

Field of application

FLOWSIC600-XT is available in variants with 4, 4+1, 4+4, and 8 measurement paths. In addition to the OIML R 137 Class 1.0 requirements, FLOWSIC600-XT meets the requirements of Class 0.5 and AGA9 in their entirety. FLOWSIC600-XT contains i diagnostics™ – an intelligent application diagnostics function – and PowerIn Technology™ for continuous measurement operation for up to three weeks in the event of a mains voltage failure. For the very best possible measurement accuracy and long-term stability.

Benefits

Low measurement uncertainty in every application
Excellent measurement data reliability and availability
The right ultrasonic gas flow measuring device for every application – without compromise

Simple device integration – even in compact systems
Quick and easy commissioning and checks
Economical quantification of the H2 content in natural gas

Spare parts & accessories

	Description	Category	Drawing No.	Order Code
1	BATTERY UNIT 3R6	further parts		2079721
2	PROBE T218 TI200MB100P18 SP	further parts		2080027
3	PROBE T210 TI200MB100P10 SP	further parts		2080032
4	PRES.SENSOR VSP1165-020-SS SP	further parts		2083110
5	PRES.SENSOR VSP1165-110-SS SP	further parts		2083118
6	PRES.SENSOR VSP1165-160-SS SP	further parts		2083119
7	PRESSURE BALANCE M121,5 1.4404 SP	further parts		2083139
8	CAP -SO 3Z AL BK SP	further parts		2083170
9	CAP -SO 3Z SS BK SP	further parts		2083171
10	CAP -SO 4Z AL BK SP	further parts		2083172
11	CAP -SO 4Z SS BK SP	further parts		2083174
12	CAP- PT 8Z-16Z BK AL SP	further parts		2083179
13	CAP- PT 8Z-16Z SS BK SP	further parts		2083180
14	CAP- PT 4Z- 6Z BK AL SP	further parts		2083181
15	CAP- PT 4Z- 6Z SS BK SP	further parts		2083182
16	CAP -SO 6Z-B AL BK SP	further parts		2085201
17	CAP -SO 6Z-A AL BK SP	further parts		2085202
18	CAP -SO 8Z-A AL BK SP	further parts		2085203
19	CAP -SO 8Z-B AL BK SP	further parts		2085204
20	CAP -SO 10Z-12Z-A AL BK SP	further parts		2085205
21	CAP -SO 10Z-12Z-B AL BK SP	further parts		2085206
22	CAP -SO 4Z RP AL BK SP	further parts		2085207
23	CAP -SO 16Z-A AL BK SP	further parts		2085214
24	CAP -SO 16Z-B AL BK SP	further parts		2085215
25	CAP -SO D83 20Z-XXZ AL BK SP	further parts		2085218
26	CAP -SO 20Z-KK AL BK SP	further parts		2085219
27	CAP -SO 24Z-KK AL BK SP	further parts		2085222
28	CAP -SO 24Z-KK 5C AL BK SP	further parts		2085223
29	CAP -SO 6Z-A SS BK SP	further parts		2085225
30	CAP -SO 6Z-B SS BK SP	further parts		2085226
31	CAP -SO 8Z-A SS BK SP	further parts		2085227
32	CAP -SO 8Z-B SS BK SP	further parts		2085228
33	CAP -SO 10Z-12Z-A SS BK SP	further parts		2085229
34	CAP -SO 10Z-12Z-B SS BK SP	further parts		2085230
35	CAP -SO 16Z-A SS BK SP	further parts		2085233
36	CAP -SO 16Z-B SS BK SP	further parts		2085234
37	PR-SEAL SET NATURAL GAS D15 SP	further parts		2085270
38	PR-SEAL SET NATURAL GAS D 7.5 SP	further parts		2085274
39	COVER,EX-D AL SR SP	further parts		2085284
40	CABLE UNIT DISPLAY SP	further parts		2085288
41	DECORATIVE EX-DE SP	further parts		2085289
42	ELECTRONIC COVER SP	further parts		2085290
43	E-PACK 200KHZ IIA 8P LS SP	further parts		2085291
44	E-PACK 200KHZ IIC 8P LS SP	further parts		2085292
45	E-PACK 200KHZ IIC 4P LS SP	further parts		2085293
46	E-PACK 300KHZ IIA 8P LS SP	further parts		2085294
47	E-PACK 135KHZ IIA 8P LS SP	further parts		2085295
48	E-PACK 135KHZ IIC 8P LS SP	further parts		2085296
49	E-PACK 135KHZ IIC 8P HS SP	further parts		2085297
50	E-PACK 80KHZ IIA 8P HS SP	further parts		2085298
51	CABLE SET I/O SP	further parts		2085300
52	CABLE SET I/O EX-D-E SP	further parts		2085301
53	PROTECTION I/O UNIT SP	further parts		2085302
54	SCREW PLUG SET EX-E SP	further parts		2085303
55	SPRING PLUG SET EX-E SP	further parts		2085304
56	I/O UNIT ETHERNET SP	further parts		2085305
57	I/O UNIT SP	further parts		2085315
58	NECK I SHORT SCREW IN AL BK SP	further parts		2085320
59	NECK I LONG SCREW IN AL BK SP	further parts		2085321
60	NECK Y HORT SCREW IN AL BK SP	further parts		2085322
61	NECK I SHORT AL BK SP	further parts		2085323
62	NECK I LONG AL BK SP	further parts		2085324
63	NECK Y SHORT AL BK SP	further parts		2085325
64	CABLE GLAND EX E PLUG HOLE M20 SP	further parts		2085329
65	PROBE S8 TI135MB100P18 SP	further parts		2094484
66	PROBE 28 TI135MB250P18 SP	further parts		2094485
67	PROBE 26 TI200MB250P10 SP	further parts		2094489
68	PROBE 22 TI200MB250P18 SP	further parts		2094490
69	PROBE S7 TI135MB016P18 SP	further parts		2094491
70	PROBE S6 TI200MB100P10 SP	further parts		2094492
71	PROBE S5 TI300MB100P10 SP	further parts		2094499
72	PROBE 15 TI300MB100P18 SP	further parts		2094501
73	PROBE S2 TI200MB100P18 SP	further parts		2094699
74	EX-I DO-HF BOARD SCREW TYPE SP	further parts		2095236
75	EX-I DO-HF BOARD SPRING TYPE SP	further parts		2095237
76	EX-I RS485 BOARD SCREW TYPE SP	further parts		2095238
77	EX-I RS485 BOARD SPRING TYPE SP	further parts		2095239
78	PLUG SET SCREW TYPE EX-I SP	further parts		2095243
79	PLUG SET SPRING TYPE EX-I SP	further parts		2095244
80	SCREW SET SP	further parts		2095246
81	PLUG SET SCREW TYPE EX-D SP	further parts		2095252
82	PLUG SET SPRING TYPE EX-D SP	further parts		2095254
83	EX-I ENC BOARD SCREW TYPE SP	further parts		2095302
84	EX-I ENC BOARD SPRING TYPE SP	further parts		2095303
85	MOUNTING SET EX-I IO SP	further parts		2095335
86	COVER, EX-D SS SR SP	further parts		2099540
87	E-PACK 200KHZ IIA 4P LS SP	further parts		2106909
88	SEAL,DISPLAY COVER SP	further parts		2111832
89	SEAL,COVER-EXD SP	further parts		2111943
90	THREADLOCKER	further parts		2116153
91	PCBA-HART-PT SP	further parts		2121476
92	COVER,DISPLAY AL SR DISP SP	further parts		2124702
93	COVER,DISPLAY SS SR DISP SP	further parts		2124728
94	COVER,EX-E AL SR DISP SP	further parts		2124737
95	COVER, EX-E SS SR DISP SP	further parts		2124739
96	COVER,DISPLAY AL SR DISP SINGLE SP	further parts		2124779
97	COVER,DISPLAY SS SR DISP SINGLE SP	further parts		2124780
98	PR-SEAL SET FR25/90 D15 SP	further parts		2125262
99	PROBE H210 TI200MB100P10 SP	further parts		2129621
100	PROBE H218 TI200MB100P18 SP	further parts		2129622
101	PROBE T240 TI200MB450P10 SP	further parts		2129624
102	E-PACK 300KHZ IIC 8P LS SP	further parts		2131374
103	MOUNTING KIT SCREWS SEALING SP	further parts		2136457
104	COVER,DISPLAY AL MC SR DISP SEAL SP	further parts		2136458
105	SET O-RING 15.02.0 FR25/90 FKM428 SP	further parts		2142375
106	SET O-RING 7.51.5 FR25/90 FKM428 SP	further parts		2142376
107	SET O-RING 11.51.5 FR25/90 FKM428 SP	further parts		2142377
108	SCREW CONNECTION NPT1/2″ ATEX AL SP	further parts		2142619
109	ADHE.TAPE,TESA 19.02M5 EXTREME BK	further parts		5337185
110	EXTENSION HT L350 GG	further parts		2032601
