Proline Prosonic Flow B 200 ultrasonic flowmeter | Endress Hauser E+H

The device for accurate, reliable biogas measurement with loop-powered technology

Automation Components

Specs at a glance

Max. measurement error Volume flow (standard): ‐ ±1.5 % o.r. for 3 to 30 m/s (9.84 to 98.4 ft/s) ‐ ±3 % o.r. for 1 to 3 m/s (3.28 to 9.84 ft/s) Volume flow (option): ‐ ±0.1 % o.f.s. for 0.3 to 1 m/s (0.98 to 3.28 ft/s) ‐ ±1.5 % o.r. for 1 to 30 m/s (3.28 to 98.4 ft/s)

Measuring range Standard: 1 to 30 m/s (3.28 to 98.4 ft/s) Option: 0.3 to 30 m/s (0.98 to 98.4 ft/s)

Medium temperature range 0 to +80 °C (+32 to +176 °F)
Max. process pressure 11 bar a (159 psi a)
Wetted materials Sensor: 1.4404/1.4435 (316L) Transducer: HNBR Temperature sensor (option): AFM 34

Field of application

Prosonic Flow B 200 is the specialist for accurate and reliable measurement of wet biogas and digester gas,even under fluctuating process conditions. With its unique integrated real-time methane fraction analysis, Prosonic Flow B 200 enables continuous measurement and monitoring of gas flow as well as gas quality. In addition to efficient process control and energy balancing, Heartbeat Technology enables compliance and process safety at all times.

Benefits

Integrated real-time methane fraction measurement
Optimized for low pressure gas – specialized sensor design
No additional pressure loss – full bore design
Process transparency – diagnostic capability
Convenient device wiring – separate connection compartment
Safe operation – no need to open the device due to display with touch control, background lighting

Integrated verification – Heartbeat Technology

Spare parts & accessories

	Description	Category	Drawing No.	Order Code
1	Electronic Prosonic Flow 200	Electronic	30	XPD0002-
2	I/O module Flow, 2-wr. 2×4-20mA,HART, Ex	I/O module	34	71108602
3	I/O module, 2-wire, 4-20mA, HART, Ex	I/O module	34	XPD0015-
4	I/O module, 2-wire, 4-20mA,HART, PFS, Ex	I/O module	34	XPD0016-
5	I/O,2-wire,4-20mA,HART,PFS,4-20mA input	I/O module	34	XPD0018-
6	Overvoltage protection (OVP10),1-Channel	further parts		71128617
7	Overvoltage protection (OVP20),2-Channel	further parts		71128619
8	Kit Display module,SD02,push buttons	Display	40	71109658
9	Display module, SD02, push buttons	Display	40	XPD0024-
10	Kit Display module,SD03,Touch Control	Display	40	71162152
11	Display module, SD03, Touch Control	Display	40	XPD0025-
12	Transmitter electronics FHX50	further parts		71197334
13	M12-female plug connector, VA	further parts		71296840
14	Cable FHX50, FHX50B, 5m	further parts		71206552
15	Cable FHX50, FHX50B, 10m	further parts		71206554
16	Cable FHX50, FHX50B, 20m	further parts		71206555
17	Cable FHX50, FHX50B, 30m	further parts		71206556
18	Terminal set 2-wire, I/O module	Terminals	37	71110280
19	Cover GT18 316L, HNBR	Cover	20	71110281
20	Cover GT18 316L, sight glass, HNBR	Cover	20	71110282
21	Cover GT18 316L, terminal Ex, HNBR	Cover	25	71110291
22	Cover GT18 316L, terminal Ex d, HNBR	Cover	25	71110284
23	Cover GT18 316L, Terminal, OVP, HNBR	Cover	25	71185516
24	Cover GT20 Alu, HNBR	Cover	20	71110299
25	Cover GT20 Alu, sight glass, HNBR	Cover	20	71110297
26	Cover GT20 Alu, Terminal Ex, HNBR	Cover	25	71110301
27	Cover GT20 Alu, Terminal Ex d, HNBR	Cover	25	71110302
28	Cover GT20 Alu, Terminal, OVP, HNBR	Cover	25	71185517
29	Kit 10 cable glands M20x1,5 grey	Connection (electrical)	15	50103658
30	Kit 10 cable glands M20x1.5 Ex	Connection (electrical)	15	50098036
31	Kit 2 cable glands M20x1.5 INOX Ex	Connection (electrical)	15	71069285
32	Kit 10 ext. M20x1.5/G 1/2″ (plug PVC)	Connection (electrical)	15	50098041
33	Kit 10 ext. M20x1,5/G 1/2″ (plug brass)	Connection (electrical)	15	71115505
34	Kit 10 ext. M20x1.5/NPT 1/2″ (plug PVC)	Connection (electrical)	15	50098042
35	Kit 10 ext. M20x1,5/NPT1/2″(plug brass)	Connection (electrical)	15	71115509
36	Sealing set GT18/GT19/GT20, EPDM, HNBR	Sealing	65	71110303
37	Housing filter 316L, GT18, 1 set	Filter	19	71115174
38	Housing filter Brass/Ni GT19/20, 1 set	Filter	19	71115175
39	Set housing securing clamps	Housing/housing accessories	17	71115176
40	Transmitter Prosonic Flow B 200, 9B2BXX	further parts		9B2BXX-
41	Sensor cable,Cable gland,Prosonic Flow B	Cable/cable accessories	53	XPD0003-
42	Sensor cable,Cable gland,Prosonic Flow B	Cable/cable accessories	53	XPD0003-
43	Sensor cable,Cable gland,Prosonic Flow B	Cable/cable accessories	53	XPD0003-
44	US Transducer, tools, Prosonic Flow B	Sensoric	51	XPD0004-
45	US Transducer, tools, Prosonic Flow B	Sensoric	51	XPD0004-
46	US Transducer, tools, Prosonic Flow B	Sensoric	51	XPD0004-
47	US Transducer, tools, Prosonic Flow B	Sensoric	51	XPD0004-
48	Plate conditioner 35 hole, Prowirl	further parts		DK7ST-
49	Spare RFID TAG	further parts		XPRFID-
50	Spare IEC TAG	further parts		XPSPEC-
51	Weather protection cov.GT18/GT19/GT20			71132889
52	Weather prot. cover GT18/GT19/GT20, 316L			71162242
53	Plate conditioner 35 hole, Prowirl			DK7ST-
