FLOWSIC200 ultrasonic flow measurement instrument | Endress Hauser E+H

The tunnel flow velocity measuring device for long-term operation

Request a Quote

Flow measurement

أجهزة قياس المستوى السائل/الصلب

أجهزة تحليل السوائل

أجهزة قياس درجة الحرارة

أجهزة قياس الضغط

System products

قطع غيار الأتمتة الصناعية

Specs at a glance

Measured variables Flow velocity, Direction of flow, temperature
Measuring range Flow Velocity: 0 … ± 20 m/s
Conformities RABT 2006 ASTRA “Guideline – Ventilation of Road Tunnels” (2008) RVS 09.02.22

Field of application

The FLOWSIC200 is used for the contact-free and accurate measurement of flow velocity and flow direction inside tunnels or exhaust ventilation ducts. Ultrasonic technology provides the cross sectional mean average value of the flow velocity. This device is used for measurement necessary for optimal ventilation control and reducing running costs to a minimum when air flow is dictated by climatic conditions or by traffic.

Benefits

Representative measurement across total tunnel width
Very reliable measurement, compared with punctual measurement methods

Accurate measurement even of very low flow velocities
Long maintenance intervals of up to 5 years
Low operating costs due to reliable operation and low maintenance
High availability of devices and, therefore, of measurement data also

Spare parts & accessories

	Description	Category	Drawing No.	Order Code
1	DIGITAL OUT 4-SIGNAL MODULE (ONLY SPU)	further parts		2034661
2	TRANSDUCER D60F18TI- 200 H	further parts		2048076
3	E-UNIT FL200 H	further parts		2048079
4	E-UNIT FL200 M	further parts		2048080
5	DOOR MCU-NWSD/N2SD W.DISPLAY	further parts		2048085
6	TUBE W.TRANSDUCER + CABLE SP	further parts		2055183
7	PLUG, 7P KONF L=250 SP	further parts		2140156
8	DIGITAL OUT 2-SIGNAL MODULE	further parts		2034659
9	MODULE PW SUPPLY COLD-DEVICE MOUN TESTED	further parts		2050590
10	MODULE POWER SUPPLY CLAMP MOUN. TESTED	further parts		2050591
11	PCBA-PROCESSOR 19Z MCU TESTED	further parts		2052234
12	FRONT PANEL MODULE MCU 19″ INST. SP	further parts		2065868
13	DUCT PROBE PH-S D60SS0750 K170	further parts		2032243
14	DUCT PROBE PH-S D60SS0550 K170	further parts		2032246
15	MOUNTING KIT K178	further parts		2047154
16	MOUNTING KIT K121	further parts		2047155
17	PCBA-E/A-PROC FRAM+RS485 SERVICE ET	further parts		2062078
18	POWER SUPPLY UNIT CORTEM HOU GEPR	further parts		2062084
19	SEALING SET RETR MECH EXS HT SP	further parts		2062105
20	HOUSING KIT RESERVE PARTS AL M20	further parts		2065857
21	CABLE DISPLAY 0.390M SP	further parts		2104412
22	PCBA-EX BARRIERE DISPLAY SP	further parts		2104413
23	PRESSURE COMP. ELEMENT M121.5 1.4404 SP	further parts		2104416
