Robust point level switch for fine-grained bulk solids also for hazardous areas
Soliphant FTM50 is a robust point level switch for use in silos containing fine-grained or powdery solids even with a low bulk density. Suitable for a wide range of applications with international certificates for use in dust or gas hazardous areas. Available with polished fork and stainless steel housing with Tri-Clamp or with aluminum housing and coated fork. Maintenance-free device for use in typical applications like: cereals, flour, cocoa, sugar, animal feed, dye powder, chalk.
| Description | Category | Drawing No. | Order Code | |
| 1 | O-ring 26.57×3.53 EPDM, 5 pieces | Sealing | 11 | 52004276 |
| 2 | Adapter set housing/electronics FTM5x | Fixing | 12 | 52028204 |
| 3 | Adapter set cable entry NPT1/2 | Adapter housing/cable entry | 15 | 52004133 |
| 4 | Adapter set cable gland M20 | Adapter housing/cable entry | 15 | 52004134 |
| 5 | Adapter set cable entry G1/2 | Adapter housing/cable entry | 15 | 52004135 |
| 6 | Cover F16 transparent, gasket | Cover | 20 | 52025790 |
| 7 | O-ring 71.0×3.55 EPDM, 5 pieces | Sealing | 21 | 52004137 |
| 8 | Cover F13 Ex Alu, gasket | Cover | 20 | 52002698 |
| 9 | Cover F13/17/18 Alu,sight glass,gasket | Cover | 20 | 52027693 |
| 10 | Cover F17 Alu, gasket | Cover | 20 | 52002699 |
| 11 | Cover F15 316L, gasket | Cover | 20 | 52027000 |
| 12 | Cover F15 316L, claw, gasket | Cover | 20 | 52027708 |
| 13 | Cover F15 316L, sight glass, gasket | Cover | 20 | 52027002 |
| 14 | Cover F15 316L,claw,sight glass,gasket | Cover | 20 | 52027709 |
| 15 | Cover F27 316L, gasket FVQM | Cover | 20 | 71185025 |
| 16 | Cover T13 Alu, gasket EPDM | Cover | 20 | 52006903 |
| 17 | Cover T13 Alu,Ex d,high,sight glass,gas. | Cover | 20 | 52028271 |
| 18 | Sealing set EPDM,cover F13/17/18/27,5pc | Sealing | 21 | 52004277 |
| 19 | Gasket 67.5×2.9×1.5 VMQ/PTFE, 5 pieces | Sealing | 21 | 52028179 |
| 20 | Sealing set EPDM 73.0×3.0, 10 pieces | Sealing | 21 | 52008495 |
| 21 | Cable entry G1/2, gasket, FTM5x | Adapter housing/cable entry | 15 | 52028180 |
| 22 | Cable entry NPT1/2, gasket, FTM5x | Adapter housing/cable entry | 15 | 52028181 |
| 23 | Cover T13 “Terminal” Alu, gasket EPDM | Cover | 25 | 52007103 |
| 24 | Cable gland M20, gasket, FTM5x | Adapter housing/cable entry | 15 | 52028182 |
| 25 | Cable gland M20 metal, gasket, FTM5x | Adapter housing/cable entry | 15 | 52028183 |
| 26 | M12 plug, 316L, APL, housing side | Adapter housing/cable entry | 15 | 71435139 |
| 27 | Electronics FEM51, AC | Electronic | 30 | 52026497 |
| 28 | Electronics FEM52, DC | Electronic | 30 | 52026498 |
| 29 | Electronics FEM54, DPDT | Electronic | 30 | 52026499 |
| 30 | Electronics FEM55, 8/16mA | Electronic | 30 | 52026500 |
| 31 | Electronics FEM57, PFM | Electronic | 30 | 52026501 |
| 32 | Electronics FEM58, NAMUR | Electronic | 30 | 52026502 |
| 33 | Sensor FTM50, Prozessanschluss | Sensoric | 50 | FTM50X- |
| 34 | Mounting set (2″/pipe 38_V4A | further parts | 919806-1000 | |
| 35 | Cable, F15/16/17 sep. | further parts | 71035208 | |
| 36 | Cable, amoured, F15/16/17 sep. | further parts | 71035209 | |
| 37 | Cable, F13/T13 sep. | further parts | 71035210 | |
| 38 | Cable, amoured, F13/T13 sep. | further parts | 71035211 | |
| 39 | Cable Exd/Exde/XP, F13/T13 sep. | further parts | 71035212 | |
| 40 | Cable amoured Exd/Exde/XP, F13/T13 sep. | further parts | 71035213 | |
| 41 | Diagnostics plug FTL5x,FTL7x,FTL8x,FTM5x | further parts | 71036514 | |
| 42 | Removing tool FTM50/FTM51/FTM52 | 71026213 | ||
| 43 | Weather protection cover F13/F17/F18/F27 | 71040497 | ||
| 44 | Protection cover F16 housing | 71127760 |
