Micropilot FMR30B – radar sensor for basic applications | Endress Hauser E+H

Simple and efficient level measurement in liquids and solids

Automation Components

Specs at a glance

Accuracy Liquids: +/- 2 mm (0.08″) Solids: +/- 4 mm (0.16″)
Process temperature -40…+80°C (-40…+176°F)
Process pressure / max. overpressure limit -1…3 bar (-14,5…43 psi)
Max. measurement distance 40 mm/ 1-1/2″: 20m (65.6 ft) 80 mm/ 3″: 30m (98.4 ft)
Main wetted parts PVDF, PBT/PC

Field of application

The Micropilot FMR30B is made for continuous non-contact level measurement equipped with 80 GHz-technology. The installation and commissioning of the device is fast and easy due to its simple design and guiding wizards. Remote access via Bluetooth or on site access via the color touch display ensures easy operation. With on demand process verification and device diagnostics, thanks to Heartbeat Technology, downtime can be reduced. The compact device is ideal for narrow installation conditions.

Benefits

Fast commissioning and operation thanks to guided setup sequences (wizards)
Bluetooth connectivity enables easy, reliable and encrypted wireless remote access
Comfortable on-site access via color touch display
Device identification during Bluetooth connection thanks to “It’s me function” (flashing display)
Simple device selection thanks to clear segmentation and easy configuration
Heartbeat Technology allows on-demand verification and diagnostics guided through the wizard without process interruption

Spare parts & accessories

	29 spare parts & accessories	Order code
1	Display with cover, FMR30B Display	71669070
2	Flat gasket EPDM 47x58x2, 5 pieces Sealing	71107559
3	Hexagon nut (SW70) G2, bk, PC further parts	52000598
4	Mounting nut G1-1/2, PC further parts	52014146
5	Sealing 63×3.5, EPDM, 5 pieces further parts	71694118
6	Spare IEC TAG further parts	XPSPEC-
7	Adapter Uni G1-1/2″>G2″, PVC	71662415
8	Adapter Uni MNPT 1-1/2″>MNPT 2″	71668921
9	Mounting bracket,75mm,G1-1/2″,NPT1-1/2″	71662419
10	Mounting bracket,200mm,G1-1/2″,NPT1-1/2″	71662423
11	Mounting nut G1-1/2, PC	52014146
12	UNI slip on flange 3″/DN80/80, PP	71162777
13	UNI slip on flange 4″/DN100/100, PP	71162778
14	UNI slip on flange 6″/DN150/150, PP	71162780
15	Sensor support 500mm, 316L, 1.5″sensor	71452318
16	Sensor support 1000mm, 316L, 1.5″ sensor	71452319
17	Bracket 700mm, 316L	71452327
18	Bracket 1400mm, 316L	71452326
19	Install. bracket 250x400x120 G1-1/2,316L	71452324
20	Install. bracket 250x400x120 G2, 316L	71452325
21	Wall bracket for sensor support, 316L	71452323
22	Weather protection cover display PBT/PC	71662268
23	Mounting device IBC tank, G1-1/2″	71770026
24	Mounting device IBC tank, NPT 1-1/2″	71775272
25	Adjustable flange, G1-1/2″	71770996
26	Adjustable flange, NPT 1‑1/2″	71775277
27	Adapter G1-1/2″ > Clamp 1-1/2″, 316L	71775274
28	Adapter NPT 1-1/2″ > Clamp 1-1/2″, 316L	71775276
29	Screw in flange FAX50	FAX50-
