Specs at a glance

Measured variables Volumetric flow a. c., volume a. c., gas velocity, sound velocity

Measuring range Gas velocity 0.3 … 60 m/s Depending on the nominal size of the pipe

Field of application

The FLOWSIC300 ultrasonic flowmeter features a unique combination of high quality components, large measuring range, simple installation, and low installation costs. It can be used anywhere where custody approval is not required: For internal measurements in the natural gas grid and with process measurements in the petrochemical industry. FLOWSIC300 incorporates proven technology and components of the rugged custody transfer quality gas flowmeters for custody transfer.

Benefits

Simple installation into existing pipelines
Efficient solution, especially for pipe diameters over 12 inches, thanks to installation onto existing pipelines and without need for a meter body

Reduced acquisition costs – the sensor extraction tool can be used for multiple devices

Low maintenance, wear and no deterioration
Low operating costs thanks to automated diagnostics and condition based maintenance

Suitable for installation in underground compartments via remote electronics and sensors with enclosure rating IP 68

Spare parts & accessories

	Description	Category	Drawing No.	Order Code
1	ELEKTRONIC BLOCK IIC/BCD 0L7 SP	further parts		2046540
2	ELEKTRONIC BLOCK IIC/BCD H 0L7 SP	further parts		2046542
3	SEALING SET CHANGE PROBE SP	further parts		2066174
4	FRONT PANEL LCD SICK FL300 INST. TESTED	further parts		2066184
5	VALVE UNIT SP	further parts		2066951
6	HYDRAULIC CYLINDER SP	further parts		2066952
7	HYDRAULIK-HAND PUMP MONT SP	further parts		2066953
8	CONNECTING CABLE ANALOG, TNC-TNC 5M SP	further parts		2066955
9	CONNECTING C ANALOG, TNC-TNC 5M EXI SP	further parts		2066956
10	CONDUIT BOX 1P 150150150 SP	further parts		2066964
11	CONDUIT BOX 2P WITH PLUG SAVEING SP	further parts		2066965
12	CONDUIT BOX 1P WITH PLUG SAVEING SP	further parts		2066967
13	CONDUIT BOX 2P 150150150 SP	further parts		2066968
14	PROPE HOLDER PULLER SP	further parts		2066972
15	ASSEMBLY SET SENDING RECEPTION UNIT SP	further parts		2066974
16	SEALING COVER MOUNT SP	further parts		2067031
17	SEALING C WITH PLUG SAVING UT MOUNT SP	further parts		2067032
18	ELEKTRONIC BLOCK 4P IIC/BCD E 1L6 SP	further parts		2067051
19	ELEKTRONIC BLOCK 4P IIC/BCD E 0L7 SP	further parts		2067053
20	THREADED ROD M121.5 D20200 ST	further parts		2067515
21	HOSE LINE HD D10,1/17,3X3M/W. COUP. SP	further parts		2067522
22	O-RING 36,0 2,5 VITON LT170-TT SP	further parts		2067525
23	HYDRAULIC OIL HLP 22 1L SP	further parts		2069733
24	INTERFACE CONVERTER RS485/USB M.SOFTWARE	further parts		6030669
25	ELECTRONIC BLOCK IIC/BCD 1L6 SP	further parts		2040387
26	ELECTRONIC BLOCK IIC/BCD H 1L6 SP	further parts		2040389
27	USB-SERVICEADAPTER	further parts		2040718
28	CONNECT. BLOCK V2 VCI6 ATEX/CSA/IEC SP	further parts		2056878
29	CONNECT. BLOCK V2 IEC SP	further parts		2062870
30	BATTERY, BUTTON 3V 0AH19 LI. BR2032	further parts		7048533
